Thermography / Oven
Validation Services
Gujarat's trusted oven validation and infrared thermography partner — hot air oven temperature mapping, depyrogenation oven qualification, loaded and empty chamber studies, infrared thermography. Full DQ/IQ/OQ/PQ per EU GMP Annex 1, WHO, Schedule M. Onsite across Gujarat.
GMP Validated
WHO · EU · FDA
250°C · 30 min
Depyrogenation
— WHAT IS OVEN / THERMOGRAPHY VALIDATION —
Oven Validation & Thermography —
Temperature Uniformity Proven
Oven validation provides documented evidence that your hot air oven or thermal processing equipment consistently maintains the required temperature uniformly at all chamber positions — essential for depyrogenation, drying, sterilization, and curing processes under GMP requirements.
Depyrogenation oven must achieve 250°C ≥30 min at coldest point
EU GMP Annex 1 (2022) requires that all glass containers used in sterile manufacturing be depyrogenated in a validated hot air oven at minimum 250°C for 30 minutes at the coldest point of the load — and this must be documented with mapping data from a qualified validation cycle.
An unvalidated oven = GMP deviation for every batch processed
If an oven used for depyrogenation, drying, or sterilization is not validated, every batch processed in that oven is potentially non-compliant — triggering batch rejection, investigation, and regulatory notification.
Infrared thermography identifies problems data loggers miss
Defective heating elements, failed door seals, insulation degradation, and hot/cold spots on the oven shell cannot be detected by internal data loggers. Infrared thermography detects these thermal anomalies non-destructively, preventing product quality failures.
Oven Validation Acceptance Criteria
EU GMP Annex 1 / WHO TRS 961 / Schedule M
Depyrogenation set-point
250°C minimum (typically 260–280°C)
Coldest point temp
≥250°C for minimum 30 minutes
Endotoxin reduction
≥3-log reduction (1000 EU → ≤1 EU)
Temp uniformity (drying)
±5°C to ±10°C of set-point
Mapping runs
Minimum 3 consecutive runs (OQ/PQ)
Data logger calibration
NABL CC-2480 certified
— WHAT YOU GET —
Every Oven Validation Includes
Onsite at Your Facility
Engineers arrive with NABL-calibrated high-temperature data loggers and infrared camera. No oven removal needed. Testing scheduled around your production.
Empty Chamber Temp Mapping
Empty oven temperature distribution study with 9–12 data loggers at standardised positions. Minimum 3 consecutive runs at all required set-points.
Loaded Chamber Mapping
Loaded mapping at worst-case load configuration (product tray, vial load, container stack). Coldest point identified and verified against process requirement.
GMP Validation Report
Full DQ/IQ/OQ/PQ report with all temperature mapping data, uniformity analysis, depyrogenation lethality calculation, deviation log — in EU GMP format within 7 days.
7-Day Report Turnaround
Preliminary temperature mapping findings within 48 hours. Complete GMP validation report with all annexures in 7 working days.
Infrared Thermography
Thermal imaging scan of oven shell, door seals, heating elements, and exhaust — identifies hot spots, cold zones, insulation failures, and thermal anomalies non-destructively.
NABL-Calibrated Data Loggers
All high-temperature data loggers (rated to 300°C+) are NABL CC-2480 calibrated with valid calibration certificates included in every validation report.
Annual Requalification Program
Scheduled annual oven requalification with fresh temperature mapping and updated calibration certificates — keeps ovens perpetually GMP-compliant.
Onsite Across Gujarat · EU GMP Annex 1 · NABL CC-2480
Ready to Validate Your Oven / Dryer?
Onsite service · 7-day report delivery · FDA, WHO, EU GMP accepted
— OUR PROCESS —
Oven / Thermography Validation Process
Design Qualification (DQ)
Review oven specifications: heating system, temperature control, number of probes, chamber volume, airflow configuration, door seal, and controller type. DQ verifies design meets URS and GMP requirements for intended use (depyrogenation, drying, sterilization, annealing).
Installation Qualification (IQ)
Verification that the oven, temperature controller, over-temperature safety cut-off, recorder/data logger connections, door seals, and utilities are installed per approved drawings, manufacturer specifications, and site requirements.
OQ — Temperature Distribution Mapping
Empty chamber temperature distribution study with minimum 9–12 NABL-calibrated data loggers placed at standardised positions. Minimum 3 consecutive runs at all set-points. Temperature uniformity and stability evaluated against acceptance criteria.
PQ — Loaded Temperature Mapping
Loaded mapping with product or load simulant at worst-case loading configuration. Temperature at coldest point verified to meet process requirement (e.g., 250°C for depyrogenation, minimum 30 min for endotoxin 3-log reduction).
Infrared Thermography (if required)
Infrared thermal imaging of oven shell, door seals, heating elements, and exhaust system to identify hot spots, cold zones, insulation failures, and thermal bridging — non-destructive, instantaneous thermal map of the entire oven surface.
Validation Report Issued
Complete DQ/IQ/OQ/PQ validation report with all temperature mapping data, uniformity analysis, thermography images (if performed), deviation log, and conclusion — GMP-ready within 7 days.
Industry Applications
Industries That Require Oven Validation
Pharmaceutical — Depyrogenation
Hot air oven validation for depyrogenation of glass vials, ampoules, and containers — temperature mapping at 250°C per EU GMP Annex 1 (2022) and US FDA 21 CFR Part 211.
Know MoreTablet & Capsule Manufacturing
Drying oven and granulation oven temperature mapping for tablet manufacturing — uniformity verification per Schedule M (2023) and WHO GMP.
Know MoreMedical Device Sterilization
Hot air oven validation for dry heat sterilization of medical devices per ISO 20857 and IEC 61010. Thermal distribution and load studies.
Know MoreAPI / Chemical Processing
Process oven and tray dryer temperature mapping for API drying, crystallization, and annealing per EU GMP and FDA 21 CFR Part 211 requirements.
Know MoreElectronics & PCB Manufacturing
Reflow oven and curing oven thermal profiling and temperature mapping for PCB assembly and electronic component manufacturing per IPC standards.
Know MoreFood Processing & Baking
Baking oven and dehydration oven temperature mapping for food manufacturers per FSSAI, FSSC 22000, and HACCP requirements.
Know MoreRubber & Plastics Curing
Curing oven temperature distribution mapping for rubber and plastics manufacturers — uniformity verification for consistent product cure.
Know MoreCoating & Paint Curing
Paint curing oven and powder coating oven temperature profiling and mapping per ISO 9001 and automotive quality requirements.
Know MoreWhy Choose Prism
Two Decades of GMP Validation.
Zero Audit Observations.
Since 2004, every oven validation report by Prism has been accepted by USFDA, WHO GMP, EU GMP, GPCB, and NABH auditors without a single observation.
— STANDARDS & COMPLIANCE —
Standards We Follow for Oven Validation
EU GMP Annex 1 (2022)
Sterile medicinal products — depyrogenation
USP <1211>
Sterilization and sterility assurance
WHO TRS 961
WHO supplement — sterilization
ISPE Baseline Guide
ISPE temperature mapping guidance
Schedule M India (2023)
Indian GMP requirements
ISO 17025:2017
NABL CC-2480 accreditation
IEC 60068 (for test ovens)
Environmental testing — thermal
ASTM E145
Gravity and forced air ovens
NABL CC-2480 + EU GMP Annex 1 (2022)
All high-temperature data loggers are NABL calibrated under CC-2480. Every oven validation report accepted in USFDA, WHO GMP, EU GMP, GPCB, and NABH audits.
700+
Ovens Validated
0
Audit Observations
— NON-GMP OVEN TESTING —
Oven Mapping for Non-GMP Applications
Food processors, electronics manufacturers, coatings plants, and research laboratories all need verified oven temperature uniformity — without full pharmaceutical GMP qualification. Prism offers oven temperature mapping for non-GMP applications using the same NABL-calibrated instruments.
NABL-Calibrated Loggers
All data loggers NABL CC-2480 calibrated — GMP and non-GMP oven mapping.
1–3 Day Completion
Simple oven temperature mapping completed in 1–3 days; full GMP validation in 5–7 days.
Flexible Scope
Mapping only, infrared thermography only, or full DQ/IQ/OQ/PQ — your choice.
Onsite — No Shutdown
All testing at your facility around your production schedule.
Onsite Coverage
Serving All
of Gujarat
Validation engineers based in Ahmedabad cover the full Gujarat pharma and industrial corridor onsite.
